MSI PRO Z690-P DDR4 Chipset Intel Z690 Chipset

MSI PRO Z690-P LGA 1700 ATX Motherboard from MSI. Featuring an LGA 1700 socket and Z690 chipset, this motherboard is compatible with Intel 12th Gen Core, Pentium Gold, and Celeron processors. Install up to 128GB of dual-channel RAM across four DDR5 memory slots, with speeds up to 6400 MHz supported via overclocking. Four M.2 and six SATA III connectors accommodate storage drives, while a PCIe 5.0 x16 slot, two PCIe 3.0 x16 slots, and a PCIe 3.0 x1 slot can be used to install various adapter cards. This board also supports AMD CrossFireX for multi-GPU setups.

Connect accessories via a USB 3.2 Gen 2x2 Type-C port, plus one USB 3.2 Gen 2, two USB 3.2 Gen 1, and four USB 2.0 Type-A ports on the rear I/O panel. An RJ45 port is also present, supporting wired 2.5 Gigabit Ethernet connections. Connect to monitors via the HDMI or DisplayPort outputs. Internal headers provide connections for liquid or air cooling, dual CPU power, a TPM module, chassis intrusion alarm, and more. Relying on the Realtek ALC 897 Audio Codec, the MSI PRO Z690-A LGA 1700 ATX Motherboard supports 8-channel audio.

• Model Name PRO Z690-P DDR4
  CPU Support Supports 12th Gen Intel®vcCore™ Processors, Pentium®vGoldvand Celeron®
  Processors CPU Socket LGA 1700
  Chipset Intel® Z690 Chipset
  Graphics
  Interface
  1x PCIe 5.0 x16 slot
  1x PCIe 3.0 x16 slot
  Supports AMD®
  CrossFire™ Technology
  Display Interface Support [email protected] as specified in HDMI 2.1, DisplayPort 1.4 –
  Requires Processor Graphics
  Memory Support 4 DIMMs, Dual Channel DDR4-5200+MHz(OC)
  Expansion Slots 1x PCIe 3.0 x16 slot
  1x PCIe 3.0 x1 slot
  Storage 3x M.2 Gen4 x4 64Gbps slots
  1x M.2 Gen3 x4 32Gbps slot
  6x SATA 6Gbps ports
  USB ports 1x USB 3.2 Gen 2x2 20Gbps (1 Type-C)
  2x USB 3.2 Gen 2 10Gbps (1 Type-A + 1 Type-C)
  6x USB 3.2 Gen 1 5Gbps (6 Type-A)
  8x USB 2.0
  I225-V 2.5G LAN
  Audio 8-Channel (7.1) HD Audio with Audio Boost
