Gigabyte GeForce RTX 3090 VISION 24GB OC Graphics Card

Gigabyte GeForce RTX 3090 VISION OC Graphics Card brings the power of real-time ray tracing and AI to your PC games. The GPU features 24GB of GDDR6X VRAM and a 384-bit memory interface, offering improved performance and power efficiency over the previous Turing-based generation.

The front panel of the card features a variety of outputs, such as DisplayPort 1.4a and HDMI 2.1. HDMI 2.1 supports up to 48 Gb/s bandwidth and a range of higher resolutions and refresh rates, including 8K @ 60fps, 4K @ 120fps, and even up to 10K. The RTX 3090 is not just about high-resolution gaming. Computationally intensive programs can utilize the GPU's 10496 cores to accelerate tasks using CUDA and other APIs.

For cooling, Gigabyte implemented the WINDFORCE 3X cooling system. The cooling system uses three 80mm fans. The airflow is split by the triangle fan edge and guided smoothly through the 3D stripe curve on the fan surface. The 3D Active Fan feature provides semi-passive cooling, which means the fans will remain off when the GPU is under a set loading or temperature for low power gaming. You can also adjust lighting effects via RGB FUSION 2.0 software.

• Graphics Processing              GeForce RTX™ 3090
• Core Clock                                1755 MHz: 1695 MHz)
• CUDA® Cores                          10496
• Memory Clock                         19500 MHz
• Memory Size                            24 GB
• Memory Type                           GDDR6X
• Memory Bus                            384 bit
• Memory Bandwidth (GB/sec) 936 GB/s
• Card Bus                                 PCI-E 4.0 x 16
• Digital max resolution            7680x4320
• Multi-view                                 4
• Card size                                  L=320 W=126 H=55 mm
• PCB Form                                ATX
• DirectX                                     12 Ultimate
• OpenGL                                     6
• Recommended PSU                750W
• Power Connectors 8 pin*2
• Output

DisplayPort 1.4a *3
HDMI 2.1 *2

• SLI Support

2‎-way NVIDIA NVLINK™
